Original Operating Instructions
APS Series – Outdoor Hybrid Inverter
Description
APS-Series 120 Operating Instructions v320 EN
Page 35 of 213
2.5 Views
2.5.1 Exterior View
Figure 13: Exterior view front
Figure 14: Exterior view back
Pos.
Description
1
Type plate and option plate
2
Mandatory sign wear hearing protection
3
Enable switch
4
Touch display
5
Axial fan
6
Water-air heat exchanger fan
7
Cable entry AC Connection
8
Safety sign
9
APS carrier
10
Air duct
Section
Description
+C1
Control unit
+C2, +C5
DC distribution
+C3, +C6
Power unit
+C4, +C7
Cooling tower
