Original Operating Instructions
APS Series – Outdoor Hybrid Inverter
Installation
APS-Series 120 Operating Instructions v320 EN
Page 110 of 213
4.6.4.1 Dimensions of the Fuse Holders
Fuse holder for 1000 V
DC
version (All dimensions given in millimetre)
Figure 90: 1000 V
DC
fuse holder right view
Fuse size
A
B
C
D
E
F
G
NH2
199
79
38
86
M10x25
245
126
NH3
209
82
38
88
M12x30
260
138
Figure 91: 1000 V
DC
fuse holder top view
Figure 92: 1000 V
DC
fuse holder left view
Fuse size
A
B
C
D
E
F
G
H
I
J
K
NH2
224
199
56
35
79
38
86
M10x25
25
10
30
NH3
239
209
56
36
82
38
88
M12x30
25
10
30
Fuse holder for 1500 V
DC
version (All dimensions given in millimetre)
Figure 93: 1500 V
DC
fuse holder
top view
Figure 94: 1500 V
DC
fuse holder
front view
Fuse Size
A
B
C
D
E
F
NH2XL
15
M10x25
30
48
40
34
NH3L
18
M12x30
40
52
59
59
