3.3 Delivery
1. Check the shock indicators for transport damage. The shock indicators are
inside the control unit (Figure 21) and on the packaging. They indicate an
improper transport.
 In case of damage, please contact the freight forwarder.
2. Check the delivery for completeness (Table 3).
 If the delivery is not complete, please contact the distributor.
3. Check the interior area of Sections +C3 and +C6 (Figure 13) for cooling system
leakage.
 In case of leakage, please contact customer service (Section 11).
Table 3: Scope of delivery
Description
Quantity
1 – 2 APUs
3 – 4 APUs
APS Outdoor hybrid inverter
1
Cooling tower
1
2
Beam
2
Original operating instructions
1
Function- and interface description
1
Wiring diagram
1
Customer specific wiring diagram
(if available)
1
APS-Configuration sheet
(if available)
1
Test record final test
1
Test record insulation monitor
1
LV-fuse inserts
Order depending
The separate packages include the material for one cooling tower/radial fan.
Table 4: Separate package for APS
Required
material
Description
Part No.
Substitute
material
1
Awning
480209
-
1
Resistor 120 Ω
210025
-
1
Funnel with filter
340821
-
6 pcs.
Cylinder head screw
420047
2 pcs.
6 pcs.
Spring lock washer
430003
2 pcs.
