WSTECH APS Series - Table 31: Additional Spare Parts List (APS with 1000 VDC ); Table 32: Additional Spare Parts List (APS with 1500 VDC )

Original Operating Instructions
APS Series – Outdoor Hybrid Inverter
Appendix
APS-Series 120 Operating Instructions v320 EN
Page 152 of 213
Table 31: Additional spare parts list (APS with 1000 V
DC
)
Item
designation
Section
Article description
Part No.
-FA110.1/
-FA210.1
+C2/+C5
Surge arrester
570046
-FC112.X/
-FC212.X
-FC113.X/
-FC213.X
+C2/+C5
PV Fuse NH2/250A
500341
See above
See above
PV Fuse NH3/400A
500381
See above
See above
Other fuse sizes available on request
-
-KF115/-KF215
+C3/+C6
Control Card cpl. 1000V / 1150 A
810200-362
-
+C3/+C6
Powerstack and DC-Link "L" APS
812600-222
-
+C3/+C6
Powerstack and DC-Link "R" APU 650
812600-223
Table 32: Additional spare parts list (APS with 1500 V
DC
)
Item
designation
Section
Article description
Part No.
-FA110.1/
-FA210.1
+C2/+C5
Surge arrester
570070
-FC112.X/
-FC212.X
-FC113.X/
-FC213.X
+C2/+C5
PV Fuse NH2XL/250A
500480
See above
See above
PV Fuse NH3L/315A
500419
See above
See above
Other fuse sizes available on request
-
-KF115/-KF215
+C3/+C6
Control Card cpl. 1500V / 1050
810200-361
-
+C3/+C6
Powerstack and DC-Link "L" APS
812000-222
-
+C3/+C6
Powerstack and DC-Link "R" APS
812000-223
