WSTECH APS Series - Sealing against Water and Dust; Table 14: Full Expansion Behaviour of the Sealing Strip

Original Operating Instructions
APS Series – Outdoor Hybrid Inverter
Installation
APS-Series 120 Operating Instructions v320 EN
Page 92 of 213
4.5.2 Sealing against Water and Dust
NOTICE: Use a self-sealing strip to protect the product against water and dirt. The cover
sealing must be attached after the MV transformer is mounted.
Required material (part of accessory MV skid):
• Approximately 2 metres self-sealing strip (Würth: DIBA-(VKP-PLUS)-35/18-
SCHWARZ-4M)
Procedure:
1. Clean the surface to be attached (Figure 77, Pos. 3).
2. Remove the masking paper and cut the beginning of the ribbon about
20 millimetres.
3. Cut the lengths (Figure 77, Pos. A and B), immediately attach the sealing strip.
NOTICE: The sealing strip has the property to extend rapidly and extremely.
4. Lay the strips quickly.
5. Wait until the sealing strip has fully expanded and check for leakage.
NOTICE: See the full expansion time in Table 14.
Table 14: Full expansion behaviour of the sealing strip
Temperature
Time
5° C
48 h
10° C
24 h
20° C
4 h
30° C
0.5 h
