4.3.1.4 Closing the Doors
NOTICE: All doors must be closed according to below procedure.
Figure 58: Door closing mechanism
NOTICE: Closing doors without pressure 3 points (below, middle and above) may
cause damage to the closing mechanism and consequent unsealing the cabinet and
failure to meet the cabinet IP.
Procedure:
1. Close the doors by pressing the 3 points (Figure 58) at the bottom, in the
middle and the top at the same time.
