Original Operating Instructions
APS Series – Outdoor Hybrid Inverter
Installation
APS-Series 120 Operating Instructions v320 EN
Page 63 of 213
Figure 39: Hole dimension of the APS carrier (APS with 3-4 APUs)
Pos.
Description
1
Power units (+C3; +C6)
2
Control unit (+C1)
3
DC distributions (+C2; +C5)
