2.4.1 Option Seismic IEEE 693
NOTICE: Mounting of a cooling tower differs to the standard procedure (Section 4.4).
The figures show the stiffening strives and their mounting points in the different
Sections.
Figure 8: Interior view front Seismic
with protective cover
Figure 9: Interior view back Seismic
with protective cover
Figure 10: Interior
view control unit
Seismic
Pos.
Description
1
Mounting point
2
Stiffening strive
Figure 11: Detail view stiffening strive
Figure 12: Detail view mounting point
Pos.
Description
1
Turnbuckle
2
Screw connection of stiffening strive attachment point
