Xerox Phaser 3250 Service Manual

3-16 Phaser 3250 Laser Printer Service Manual
Error Messages and Codes
Multi Feeding
Multiple sheets of paper are picked from the tray at the same time.
The LED is not lit on the Control Panel even when the paper tray is empty.
Applicable Error Message
■ Multiple Feeding
Initial Actions
■ Inspect the tray to ensure that it is free of obstructions, is loaded with
supported paper, and the Guides are adjusted correctly.
■ Try picking paper from a different tray.
■ Check the paper path for obstructions or debris.
■ Cycle printer power.
■ If the problem persists, refer to the following procedure.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Pick-Up Solenoid, PL6.1.37
■ Feed Actuator, PL6.1.72
■ Holder Pad, PL11.1.4
■ “Map 6 - Main Motor, Interlock Switch,
Fans, and Sensors” on page 10-14
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 1.Check the left and right Guides of
the tray to ensure they are set
correctly.
2.Are the Guides set correctly?
Go to step 2. Adjust the left
and right
Guides.
2 1.Check the Friction Pad for
contamination or damage.
2.Is the Friction Pad contaminated or
damaged?
Clean the
Friction Pad.
Replace the Tray
Pad Holder
(page 8-8), if
damaged.
Go to step 3.
3 1.Check the Pick-Up Solenoid for
correct installation and damage.
Reseat the Pick-Up Solenoid
(page 8-39).
2.Does the error still occur?
Replace the
Pick-Up
Solenoid
(page 8-39).
Complete.

Xerox Phaser 3250 Specifications

General

Color	No
Print technology	Laser
Maximum resolution	600 x 600 DPI
Warm-up time (from sleep mode)	15 s
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	28 ppm
Internal memory	32 MB
Maximum internal memory	160 MB
Sound power level (standby)	29 dB
Sound pressure level (printing)	54 dB
Total input capacity	251 sheets
Maximum input capacity	501 sheets
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Functions	Print
I/O ports	USB 2.0
Device manager	Printer Setting Utility for Windows
Package length	561.33 mm
Depth (imperial)	14.5 \
Width (imperial)	14.3 \
Height (imperial)	9.4 \
Weight (imperial)	26.19 lbs
Power requirements	240 V, 50/60 Hz
Storage drive type	N/A
Hardware scan resolution	1200 x 1200 DPI
Storage temperature (T-T)	32 - 104 °F
Power consumption (active)	400 W
Compatible operating systems	Fedora Core 1, Red Hat 9, SUSE 9 Windows 2000/Vista
Non-operating relative humidity (non-condensing)	20 - 80 %
Country of origin	China
Maximum duty cycle	30000 pages per month
Recommended duty cycle	4000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	70 W
Power consumption (PowerSave)	11 W
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	10 - 80 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 2004/108/EC, 2006/95/EC
Package width	472.43 mm
Package height	342.89 mm
Package weight	11884.3 g

Weight and Dimensions

Depth	369 mm
Width	364 mm
Height	239.2 mm
Dimensions (WxDxH)	364 x 369 x 239.2 mm
