Xerox Phaser 3250 Service Manual

2-24 Phaser 3250 Laser Printer Service Manual
Theory of Operation
Engine F/W
Control Algorithm
Feeding
When feeding from a paper tray, the drive of the Pick-Up Roller is controlled
by the Solenoid.
The printer feeds the paper from the Manual Feeder according to information
provided by the Manual Feed Sensor, and by driving the Main Motor, insert
the paper in front of the Feed Sensor.
Different types of Jam are provided in the following table:
Jam Errors
Item Description
JAM 0 This is an indication that the leading edge of the paper did not
pass the Feed Sensor.
■ After paper pick, paper does not enter the printer.
■ After paper pick, paper enters the printer, but does not reach
the Feed Sensor in the specified time.
■ If paper has been picked, and the Feed Sensor is not On, the
printer will re-pick. If after re-picking, the Feed Sensor is still
not reported as On, this error will occur.
This is an indication that the leading edge of the paper already
passed the Feed Sensor.
■ Even though paper reaches the Feed Sensor, the Feed Sensor
is not On.
JAM 1 This is an indication that the paper is between the Feed Sensor
and the Exit Sensor.
■ After the leading edge of the paper passes the Feed Sensor,
the trailing edge of the paper cannot pass the Feed Sensor in
the specified time. (The Feed Sensor cannot be Off.)
■ After the leading edge of the paper passes the Feed Sensor,
paper cannot reach the Exit Sensor in the specified time. (The
Exit Sensor cannot be Off.)
JAM 2 After the trailing edge of the paper passes the Feed Sensor,
paper cannot pass the Exit Sensor in the specified time.
DUPLEX JAM 1 After the trailing edge of the paper passes the Exit Sensor, the
leading edge of the paper cannot reach the Regi Sensor in the
specified time.
DUPLEX JAM 0 After the leading edge of the paper passes the Regi Sensor, the
leading edge of the paper cannot reach the Feed Sensor in the
specified time.

Xerox Phaser 3250 Specifications

General

Color	No
Print technology	Laser
Maximum resolution	600 x 600 DPI
Warm-up time (from sleep mode)	15 s
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	28 ppm
Internal memory	32 MB
Maximum internal memory	160 MB
Sound power level (standby)	29 dB
Sound pressure level (printing)	54 dB
Total input capacity	251 sheets
Maximum input capacity	501 sheets
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Functions	Print
I/O ports	USB 2.0
Device manager	Printer Setting Utility for Windows
Package length	561.33 mm
Depth (imperial)	14.5 \
Width (imperial)	14.3 \
Height (imperial)	9.4 \
Weight (imperial)	26.19 lbs
Power requirements	240 V, 50/60 Hz
Storage drive type	N/A
Hardware scan resolution	1200 x 1200 DPI
Storage temperature (T-T)	32 - 104 °F
Power consumption (active)	400 W
Compatible operating systems	Fedora Core 1, Red Hat 9, SUSE 9 Windows 2000/Vista
Non-operating relative humidity (non-condensing)	20 - 80 %
Country of origin	China
Maximum duty cycle	30000 pages per month
Recommended duty cycle	4000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	70 W
Power consumption (PowerSave)	11 W
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	10 - 80 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 2004/108/EC, 2006/95/EC
Package width	472.43 mm
Package height	342.89 mm
Package weight	11884.3 g

Weight and Dimensions

Depth	369 mm
Width	364 mm
Height	239.2 mm
Dimensions (WxDxH)	364 x 369 x 239.2 mm
