Xerox Phaser 3250 Service Manual

Phaser 3250 Laser Printer Service Manual 3-29
Error Messages and Codes
Laser Unit Not Ready
All LEDs are blinking on the Control Panel. An error was detected in the Laser
Unit. Error includes PMotor Error or HSYNC Error.
Applicable Error Message
■ LSU Not Ready (LSU Scanner Motor not ready)
■ LSU Not Ready (HSYNC signal not output)
■ Black LSU Lock Error
■ Black HSYNC Error
Initial Actions
■ Cycle printer power.
■ If the problem persists, refer to the following procedure.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Main Controller Board, PL1.1.2
■ Laser Unit, PL1.1.12
■ “Map 8 - Laser Unit” on page 10-16
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 1.Check the wiring harness
connections between the Laser Unit
and the Main Controller Board.
2.Are the wiring harness connectors
securely connected?
Go to step 2. Reconnect the
connectors.
2 1.Check the Laser Unit for correct
installation. Reseat the Laser Unit
(page 8-57).
2.Does the error still occur?
Replace the
Laser Unit
(
page 8-57).
Replace the
Main Controller
Board
(
page 8-62).

Xerox Phaser 3250 Specifications

General

Color	No
Print technology	Laser
Maximum resolution	600 x 600 DPI
Warm-up time (from sleep mode)	15 s
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	28 ppm
Internal memory	32 MB
Maximum internal memory	160 MB
Sound power level (standby)	29 dB
Sound pressure level (printing)	54 dB
Total input capacity	251 sheets
Maximum input capacity	501 sheets
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Functions	Print
I/O ports	USB 2.0
Device manager	Printer Setting Utility for Windows
Package length	561.33 mm
Depth (imperial)	14.5 \
Width (imperial)	14.3 \
Height (imperial)	9.4 \
Weight (imperial)	26.19 lbs
Power requirements	240 V, 50/60 Hz
Storage drive type	N/A
Hardware scan resolution	1200 x 1200 DPI
Storage temperature (T-T)	32 - 104 °F
Power consumption (active)	400 W
Compatible operating systems	Fedora Core 1, Red Hat 9, SUSE 9 Windows 2000/Vista
Non-operating relative humidity (non-condensing)	20 - 80 %
Country of origin	China
Maximum duty cycle	30000 pages per month
Recommended duty cycle	4000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	70 W
Power consumption (PowerSave)	11 W
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	10 - 80 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 2004/108/EC, 2006/95/EC
Package width	472.43 mm
Package height	342.89 mm
Package weight	11884.3 g

Weight and Dimensions

Depth	369 mm
Width	364 mm
Height	239.2 mm
Dimensions (WxDxH)	364 x 369 x 239.2 mm
