Xerox Phaser 3250 Service Manual

2-2 Phaser 3250 Laser Printer Service Manual
Theory of Operation
Phaser 3250 Operational Overview
The Phaser 3250 is a monochrome laser printer that uses Laser Scanner Unit
(LSU) with an electrophotographic process. The printer system consists of
one print cartridge which creates toner image.
System Overview
The Phaser 3250 Laser Printer consists of the Feeding Mechanism, Drive
Assembly, Transfer Roller, Fuser, Laser Unit, Control Panel, and Printer
Controller.
■ Feeding Mechanism: The Feeding mechanism consists of the Manual
Feeder, Tray 1, Tray 2, Pick-Up Roller, Tray Holder Pad, and Feed Rollers.
The rollers and sensors in the paper feed path control paper registration
and guide the paper through the image transfer, image development,
image fusing, and exit assemblies.
■ Drive Assembly: The Drive Assembly receives power from the Main
Controller Board, The Main Motor provides drive energy to the paper feed,
Toner Cartridge, Fuser, Pick-Up Roller, Feed Rollers, and Duplex Unit.
The Drive Assembly consists of a Main Motor.
■ Main Motor: DC 24V
■ Rated RPM: 2170 rpm
■ Transfer Roller: The Transfer Roller transfers toner on an Organic Photo
Conductor (OPC) to the paper.
■ Fuser: The Fuser consists of a Heat Lamp, Heat Roller, Pressure Roller,
Thermistor, and Thermostat. The Fuser applies toner on to paper using
heat and pressure.
■ Laser Unit: The Laser Unit is an exposure unit that generates laser
beams to form electrostatic latent image on the drum surface.
■ Control Panel: The Control Panel displays LED status of the printer.
■ Printer Controller: The Printer Controller controls the total system of the
machine. The Printer Controller processes and stores images from the
Print Engine, printer I/F, and controls the panel.

Xerox Phaser 3250 Specifications

General

Color	No
Print technology	Laser
Maximum resolution	600 x 600 DPI
Warm-up time (from sleep mode)	15 s
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	28 ppm
Internal memory	32 MB
Maximum internal memory	160 MB
Sound power level (standby)	29 dB
Sound pressure level (printing)	54 dB
Total input capacity	251 sheets
Maximum input capacity	501 sheets
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Functions	Print
I/O ports	USB 2.0
Device manager	Printer Setting Utility for Windows
Package length	561.33 mm
Depth (imperial)	14.5 \
Width (imperial)	14.3 \
Height (imperial)	9.4 \
Weight (imperial)	26.19 lbs
Power requirements	240 V, 50/60 Hz
Storage drive type	N/A
Hardware scan resolution	1200 x 1200 DPI
Storage temperature (T-T)	32 - 104 °F
Power consumption (active)	400 W
Compatible operating systems	Fedora Core 1, Red Hat 9, SUSE 9 Windows 2000/Vista
Non-operating relative humidity (non-condensing)	20 - 80 %
Country of origin	China
Maximum duty cycle	30000 pages per month
Recommended duty cycle	4000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	70 W
Power consumption (PowerSave)	11 W
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	10 - 80 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 2004/108/EC, 2006/95/EC
Package width	472.43 mm
Package height	342.89 mm
Package weight	11884.3 g

Weight and Dimensions

Depth	369 mm
Width	364 mm
Height	239.2 mm
Dimensions (WxDxH)	364 x 369 x 239.2 mm
