Phaser 3250 Laser Printer Service Manual 10-5
Plug/Jack and Wiring Diagrams
Plug/Jack Locators
Maps 1 through 9 indicate the location of key connections within the printer.
Connections are referenced by their P/J designation.
1. Map 1 - Main Controller Board
2. Map 2 - HVPS
3. Map 3 - LVPS
4. Map 4 - Fuser
5. Map 5 - General Wiring Diagram
6. Map 6 - Main Motor, Interlock Switch, Fans, and Sensors
7. Map 7 - LVPS, HVPS, Fuser, Developer Unit CRUM, and Power Switch
8. Map 8 - Laser Unit
9. Map 9 - Optional Tray 2 and Control Panel
