Phaser 3250 Laser Printer Service Manual 4-7
General Troubleshooting
SPOOL Error
Simultaneous Peripheral Operations Online (SPOOL) is the process Windows
uses to manage print jobs. Jobs are processed and then stored on the hard
disk until the printer is ready to accept them.
1. Insufficient disk space on the hard disk in the directory assigned for the
basic spool.
a. Delete any unnecessary files to provide more disk space for spool
storage.
2. If previous printing errors were not solved.
a. There may be files from previous failed print jobs on the hard disk with
the name in the form “*.jnl”. Delete these files and reboot Windows to
restart the printer.
3. There may be a conflict with other drivers or programs.
a. Shut down all other programs except the current one, if possible.
4. When an application program or the printer driver is damaged.
a. After rebooting the computer, check for viruses, restore the damaged
files and reinstall the application program which is not working
properly.
5. Computer memory is insufficient to support printing.
a. Add more memory to the PC.
How to Delete the Data in the SPOOL Manager
In the SPOOL Manager, the installed drivers and the list of documents waiting
to be printed are shown. Select the document to be deleted and click Delete in
the menu.
If the job you are deleting is the current job, any data that has already been
transferred to the printer’s memory will still be printed. If there is a problem
with the printer (out of toner, out of paper, etc...), the job may take a long time
to delete as it must wait for a time out.

Xerox Phaser 3250 Specifications

General

Color	No
Print technology	Laser
Maximum resolution	600 x 600 DPI
Warm-up time (from sleep mode)	15 s
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	28 ppm
Internal memory	32 MB
Maximum internal memory	160 MB
Sound power level (standby)	29 dB
Sound pressure level (printing)	54 dB
Total input capacity	251 sheets
Maximum input capacity	501 sheets
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Functions	Print
I/O ports	USB 2.0
Device manager	Printer Setting Utility for Windows
Package length	561.33 mm
Depth (imperial)	14.5 \
Width (imperial)	14.3 \
Height (imperial)	9.4 \
Weight (imperial)	26.19 lbs
Power requirements	240 V, 50/60 Hz
Storage drive type	N/A
Hardware scan resolution	1200 x 1200 DPI
Storage temperature (T-T)	32 - 104 °F
Power consumption (active)	400 W
Compatible operating systems	Fedora Core 1, Red Hat 9, SUSE 9 Windows 2000/Vista
Non-operating relative humidity (non-condensing)	20 - 80 %
Country of origin	China
Maximum duty cycle	30000 pages per month
Recommended duty cycle	4000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	70 W
Power consumption (PowerSave)	11 W
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	10 - 80 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 2004/108/EC, 2006/95/EC
Package width	472.43 mm
Package height	342.89 mm
Package weight	11884.3 g

Weight and Dimensions

Depth	369 mm
Width	364 mm
Height	239.2 mm
Dimensions (WxDxH)	364 x 369 x 239.2 mm
