Xerox Phaser 3250 Service Manual

Phaser 3250 Laser Printer Service Manual 1-15
General Information
Image Specifications
Note
The printer has 4 mm margins on all sides. Edge-to-edge printing will not
be available.
■ Refer to “Print-Quality Troubleshooting” on page 5-1 for detailed
troubleshooting.
Print Margins
Print Area Margin
Guaranteed Print
Quality Area
Paper Width (A+B) A = Left Margin 4.23 mm
B = Right Margin 4.23 mm
Paper Length
(C+D)
C = Top Margin 4.23 mm
D = Bottom Margin 4.23 mm
Printable Area Paper Width (A+B) A = Left Margin 3 mm
B = Right Margin 3 mm
Paper Length
(C+D)
C = Top Margin 3 mm
D = Bottom Margin 3 mm
Characteristic Specifications
Skew
Vertical 241.3 mm (9.5 in.) ± 2.0 mm (.08 in.)
Tray 3, Duplex: 241.3 mm (9.5 in.) ± 2.5 mm (.09 in.)
Horizontal 177.8 mm (7.0 in.) ± 1.5 mm (.06 in.)
Tray 3, Duplex: 241.3 mm (9.5 in.) ± 2.0 mm (.08 in.)
Linearity
Horizontal 200 mm (7.9 in.) ± 0.5 mm (.02 in.)
Magnification
Horizontal 177.8 mm (7.0 in.) ± 1.8 mm (.07 in.)
Vertical 241.3 mm (9.5 in.) ± 2.4 mm (.09 in.)
Registration
Left Print Position
(scanning direction)
Simplex: 2.5 mm (.09 in.)
Duplex: 3.0 mm (1.2 in.)
Top Print Position
(feeding direction)
Simplex: 3.0 mm (1.2 in.)
Duplex: 3.0 mm (1.2 in.)

Xerox Phaser 3250 Specifications

General

Color	No
Print technology	Laser
Maximum resolution	600 x 600 DPI
Warm-up time (from sleep mode)	15 s
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	28 ppm
Internal memory	32 MB
Maximum internal memory	160 MB
Sound power level (standby)	29 dB
Sound pressure level (printing)	54 dB
Total input capacity	251 sheets
Maximum input capacity	501 sheets
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Functions	Print
I/O ports	USB 2.0
Device manager	Printer Setting Utility for Windows
Package length	561.33 mm
Depth (imperial)	14.5 \
Width (imperial)	14.3 \
Height (imperial)	9.4 \
Weight (imperial)	26.19 lbs
Power requirements	240 V, 50/60 Hz
Storage drive type	N/A
Hardware scan resolution	1200 x 1200 DPI
Storage temperature (T-T)	32 - 104 °F
Power consumption (active)	400 W
Compatible operating systems	Fedora Core 1, Red Hat 9, SUSE 9 Windows 2000/Vista
Non-operating relative humidity (non-condensing)	20 - 80 %
Country of origin	China
Maximum duty cycle	30000 pages per month
Recommended duty cycle	4000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	70 W
Power consumption (PowerSave)	11 W
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	10 - 80 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 2004/108/EC, 2006/95/EC
Package width	472.43 mm
Package height	342.89 mm
Package weight	11884.3 g

Weight and Dimensions

Depth	369 mm
Width	364 mm
Height	239.2 mm
Dimensions (WxDxH)	364 x 369 x 239.2 mm
