Xerox Phaser 3250 - Stains on the Back of the Page

5-32 Phaser 3250 Laser Printer Service Manual
Print-Quality Troubleshooting
Stains on the Back of the Page
The background of the back of the page is stained at 47.0 mm or 62.8 mm.
Initial Actions
■ Check the paper transfer path.
■ Ensure there are no debris on the transfer path.
Troubleshooting Reference Table
Applicable Parts Example Print
■ Transfer Roller, PL1.1.11
■ Fuser, PL9.1.0
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 1.Check the Transfer Roller for
contamination.
2.Is the Transfer Roller surface dirty?
Perform PC
cleaning
procedure (refer
to
“Printing the
Print Cleaning
Page” on
page 7-5).
Go to step 2.
2 1.Replace the Transfer Roller
(page 8-10).
2.Does the error still occur?
Replace the
Fuser
(
page 8-13).
Complete.
