Phaser 3250 Laser Printer Service Manual 1-5
General Information
Duplex Unit
The Phaser 3250 includes a Duplex Unit. User can install the Duplex Unit
without using any tools.
LAN (Network Model)
The Phaser 3250 can be used with a wired LAN.
LED State Printer State
Active LED Random Blink Normal NPC & Normal packet receive
Active LED Regular Blink Normal NPC & No Packet
Active LED Off/On Maintenance NPC Initial Error
Link LED On Link LED On, Normally linked
Link LED Off Link LED Off, Link Error
s3250-006
RJ-45 Jack
Link LED(Green)
Active LED(Orange)
s3250-004
