Xerox Phaser 3250 Service Manual

5-2 Phaser 3250 Laser Printer Service Manual
Print-Quality Troubleshooting
Print-Quality Problems Overview
Print-quality defects can be attributed to printer components, consumables,
media, internal software, external software applications, and environmental
conditions. To successfully troubleshoot print-quality problems, eliminate as
many variables as possible. The first step is to generate prints using
information pages embedded in the printer on laser paper from the approved
media list. Refer to
“Media and Tray Specifications” on page 1-18 for
supported and specialty media that have been tested and approved for use in
the Phaser 3250. Use paper from a fresh ream that is acclimated to room
temperature and humidity.
If the print-quality defect is still present when printing on approved media from
an unopened ream of paper, then investigate software applications and
environmental conditions.
Check the temperature and humidity under which the printer is operating.
Compare this to the
“Environmental Specifications” on page 1-12. Extreme
temperature and humidity can adversely affect the xerographic and fusing
characteristics of the printer.
When analyzing a print-quality defect, determine if the defect is repeating or
random occurrence. Continuous defects in the process direction, such as
Voids and Lines, are the most difficult to diagnose. Inspect the visible surfaces
of all Rollers for obvious defect. If no defects are found, replace the Print
Cartridge, Transfer Roller, Fuser, and Laser Unit one at a time until the defect
is eliminated.
Defects Associated with Specific Printer Components
Some print-quality problems can be associated with specific assemblies; the
most common problems and the associated assemblies are listed in this
section. Refer to the specific print-quality troubleshooting procedure for detail
information.
Laser Unit
■ Black Print (page 5-16)
■ Vertical White Line (page 5-25)
Transfer Roller
■ Uneven Density (page 5-18)
■ Background Contamination (page 5-19)
■ Ghosting (1) (page 5-21)
■ Vertical White Line (page 5-25)
■ Vertical Black Line and Band (page 5-27)
■ Stains on the Front of the Page (page 5-31)
■ Stains on the Back of the Page (page 5-32)

Xerox Phaser 3250 Specifications

General

Color	No
Print technology	Laser
Maximum resolution	600 x 600 DPI
Warm-up time (from sleep mode)	15 s
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	28 ppm
Internal memory	32 MB
Maximum internal memory	160 MB
Sound power level (standby)	29 dB
Sound pressure level (printing)	54 dB
Total input capacity	251 sheets
Maximum input capacity	501 sheets
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Functions	Print
I/O ports	USB 2.0
Device manager	Printer Setting Utility for Windows
Package length	561.33 mm
Depth (imperial)	14.5 \
Width (imperial)	14.3 \
Height (imperial)	9.4 \
Weight (imperial)	26.19 lbs
Power requirements	240 V, 50/60 Hz
Storage drive type	N/A
Hardware scan resolution	1200 x 1200 DPI
Storage temperature (T-T)	32 - 104 °F
Power consumption (active)	400 W
Compatible operating systems	Fedora Core 1, Red Hat 9, SUSE 9 Windows 2000/Vista
Non-operating relative humidity (non-condensing)	20 - 80 %
Country of origin	China
Maximum duty cycle	30000 pages per month
Recommended duty cycle	4000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	70 W
Power consumption (PowerSave)	11 W
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	10 - 80 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 2004/108/EC, 2006/95/EC
Package width	472.43 mm
Package height	342.89 mm
Package weight	11884.3 g

Weight and Dimensions

Depth	369 mm
Width	364 mm
Height	239.2 mm
Dimensions (WxDxH)	364 x 369 x 239.2 mm
