Xerox Phaser 3250 - Rear Cover (PL5.1.0)

8-28 Phaser 3250 Laser Printer Service Manual
Service Parts Disassembly
Rear Cover (PL5.1.0)
1. Remove the Duplex Unit (page 8-37).
2. Open the Rear Cover.
3. Press the Rear Cover toward one side to release the notch from the
printer frame.
4. Remove the Rear Cover.
Notches
s3250-080
