Phaser 3250 Laser Printer Service Manual 8-35
Service Parts Disassembly
9. Use a flat tip screw driver to pry the bottom of the Right Cover from the 2
bosses on the bottom of the printer.
10. Slide the Right Cover out to remove the Right Cover.
Place the front side of the Right Cover at an angle to secure the latch
of the Right Cover to the notch on the printer frame while sliding the
Right Cover toward the printer.
To Next Page
