9-6 Phaser 3250 Laser Printer Service Manual
Parts List
Parts List 1.1 Main
ID No. Name/Description Part Number
0. Set - MEA Unit Cover Top (P3250DN) 002N02738
1. Shield Controller
2. PBA Main Controller (P3250 D)
140N63323
PBA Main Controller (P3250 DN)
140N63322
3. HVPS 105N02147
4. SMPS-PSP-Type 2 V2C (110V) (LVPS) 105N02139
SMPS-PSP-Type 2 V2C (220V) (LVPS) 105N02140
5. CBF Harness Fuser AC (SMPS)
6. Cable from Conn Coax
7. CBF Harness HVPS
8. ELA Unit Drive (Drive Assembly) 007N01601
9. CBF Harness Motor & Solenoid
10. CBF Harness AC Inlet
11. Roller Transfer 022N02354
12. ELA Unit LSU (Laser Unit) 122N00279
13. MEA Unit Duplex 097N01682
14. Duplex Rear Cover Assy 002N02736
14-1. Cover Duplex
14-2. Cover Rear Duplex
15. Cover Top Lower 002N02739
16-1. MEA Unit Cover Left 002N02731
16-2. MEA Unit Cover Right (P3250D) 002N02733
MEA Unit Cover Right (P3250DN) 002N02732
16-3. MEA Unit Cover Rear 002N02734
16-4. MEA Unit Cover Front 002N02735
17. MEA Unit Cassette 050N00521
18. ELA Unit SCF (Optional Tray 2) 098N02194
19. CBF-Power Cord, 110V 105N02072
CBF-Power Cord, 220V 117N01769
20. ELA HOU-DEVE (Print Cartridge - 3.5K) 106R01373
ELA HOU-DEVE (Print Cartridge - 5K) 106R01374
21. Cover Top Upper
