9-26 Phaser 3250 Laser Printer Service Manual
Parts List
Parts List 9.1 Fuser
ID No. Name/Description Part Number
0. ELA Unit Fuser (110V) 126N00295
ELA Unit Fuser (220V) 126N00296
1. Cover Fuser
2. PMO Roller Upper DP
3. Roller Idle
4. IEX Shaft Idle, F/Up
5. Thermistor NTC Assy 130N01539
6. Screw Taptite
7. Thermostat 130N01490
8. Screw Taptite
9. Ground Fuser
10. Roller Heat 022N02356
11. Gear Fuser
12. Bush HR-L
13. Bush HR-R
14. PEX Roller F/Up (2)
15. Spring ETC
16. Guide Claw
17. Spring ETC Claw
18. Spring TS
19. Actuator Exit 120N00524
20. Frame Fuser
21. Roller Pressure 022N02357
22. Bush PR-1st
23. Roller Pressure-2nd 022N02358
24. Bush PR-2nd
25. Lever Link Jam-R
26. Lever Link Jam-L
27. Spring CS
28. Ring-C
29. Spring ES
30. Lamp Halogen, 110V 122N00269
Lamp Halogen, 220V 122N00270
31. CAP Lamp-L
32. CAP Lamp-R
33. Gear Fuser RDCN 28-20
34. Gear MPF 5
35. Washer Plain
36. Ring CS
37. Photo Interrupter (Exit Sensor) 130N01274
