9-28 Phaser 3250 Laser Printer Service Manual
Parts List
Parts List 10.1 Duplex Unit
ID No. Name/Description Part Number
0.
ELA Unit Duplex 097N01682
1. Frame Duplex Base
2. Terminal GND-DUP L
3. Terminal GND-DUP S
4. Bush M Feed, DUP
5. Roller Feed-DUP2
6. Ring-C
7. Pulley M-18 Dummy-DUP
8. Pulley 18-DUP
9. Gear Exit F/Down
10. Belt Timing Gear
11. Belt Timing Gear
12. ELA Unit Roller-DUP
12-1. Roller Feed-DUP
12-2. Ring-C
13. Bracket Duplex-Align
14. Screw Tapping
15. Guide Duplex-Upper
16. Roller M-Idle-DUP
17. PCT-SILP Washer
18. Shaft Idle Roll, DUP
19. Spring-TS
20. Screw Taptite
