9-30 Phaser 3250 Laser Printer Service Manual
Parts List
Parts List 11.1 Tray 1
ID No. Name/Description Part Number
0.
MEA Unit Cassette (Tray 1) 050N00521
1. Frame-M Cassette
2. Guide-M Extension L2
3. PMO Extension Small
4. Adjust-M Cassette-R
5. Adjust-M Cassette-L
6. Gear Pinion
7. Screw Taptite
8. Plate-P Knock-Up
9. CAM-M Knock-Up
10. Screw Taptite
11. Spring-CS
12. PMO Plate-Locker
13. Spring ETC-Locker, Plate
14. ELA HOU Holder-Pad 019N00957
14-1. Holder Pad
14-2. RPR-Friction Pad
14-3. Plate Pad
14-4. Sheet Pad
14-5. Ground Pad
14-6. Spring ETC Exit Roll FD
15. Housing Holder Pad
16. Cover Handle-Cassette
17. Spring-ES
18. Roller-M Idle Feed
19. Screw Taptite
20. Indicator Paper
21. Sheet Guide-Side-Far
22. Sheet Guide-Side-Near
To Next Page
