Xerox Phaser 3250 Service Manual

9-32 Phaser 3250 Laser Printer Service Manual
Parts List
Parts List 12.1 Tray 2
ID No. Name/Description Part Number
0.
ELA Unit SCF (Optional 250-Sheet Feeder) 098N02194
1. MEA Unit Cassette (Tray 2) 050N00521
2. Cover Front-SCF
3. Cover Right-SCF
4. Cover Left-SCF
5. Cover Rear-SCF
6. Cover Duplex
7. Cover Rear Duplex
8. Screw Taptite
9. ELA HOU Motor-SCF
9-1. Bracket Motor-SCF
9-2. Support Feed-SCF
9-3. Gear Idle 59
9-4. Gear 61/47 Idle
9-5. Gear Idle 23
9-6. Gear-35 Idle
9-7. Gear RDCN 57/18
9-8. Bracket Gear-SCF
9-9. Motor Step
9-10. PMO Impeller-DRV
9-11. Screw Taptite
9-12. Washer Plain
10. MEA Unit Pick-Up
10-1. Housing-M Pick-Up R2
10-2. Rubber Pick-Up
10-3. Housing-M Pick-Up UP2-R2
11. ELA HOU Frame-SCF
11-1. Frame SCF
11-2. Sheet Cover Sensor
11-3. IPR Ground Top
11-4. Screw Taptite
11-5. PMO Locker CST
11-6. PMO Actuator Empty
11-7. Sheet Brush
11-8. MEC Brush Antistatic
11-9. Foot ML80
11-10. Foot Front
11-11. Cover Harness-SCF
11-12. Cover M-SIMM R2
11-13. PBA SCF

Xerox Phaser 3250 Specifications

General

Color	No
Print technology	Laser
Maximum resolution	600 x 600 DPI
Warm-up time (from sleep mode)	15 s
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	28 ppm
Internal memory	32 MB
Maximum internal memory	160 MB
Sound power level (standby)	29 dB
Sound pressure level (printing)	54 dB
Total input capacity	251 sheets
Maximum input capacity	501 sheets
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Functions	Print
I/O ports	USB 2.0
Device manager	Printer Setting Utility for Windows
Package length	561.33 mm
Depth (imperial)	14.5 \
Width (imperial)	14.3 \
Height (imperial)	9.4 \
Weight (imperial)	26.19 lbs
Power requirements	240 V, 50/60 Hz
Storage drive type	N/A
Hardware scan resolution	1200 x 1200 DPI
Storage temperature (T-T)	32 - 104 °F
Power consumption (active)	400 W
Compatible operating systems	Fedora Core 1, Red Hat 9, SUSE 9 Windows 2000/Vista
Non-operating relative humidity (non-condensing)	20 - 80 %
Country of origin	China
Maximum duty cycle	30000 pages per month
Recommended duty cycle	4000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	70 W
Power consumption (PowerSave)	11 W
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	10 - 80 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 2004/108/EC, 2006/95/EC
Package width	472.43 mm
Package height	342.89 mm
Package weight	11884.3 g

Weight and Dimensions

Depth	369 mm
Width	364 mm
Height	239.2 mm
Dimensions (WxDxH)	364 x 369 x 239.2 mm
