Xerox Phaser 3250 Service Manual

2-22 Phaser 3250 Laser Printer Service Manual
Theory of Operation
AC Input
■ Input Rated Voltage:
■ AC 220 V~240 V
■ AC 110 V~127 V
■ Input Voltage Fluctuation Range:
■ AC 198 V~264 V
■ AC 99 V~135 V
■ Rated Frequency Fluctuating Range: 47~63 Hz
■ Input Current: Under 4.0 Arms/2.0 Arms (when the e-coil is Off or rated
voltage is inputted/outputted)
Rated Output Power
No. Item CH1 CH2 Remark
1 CHANNEL NAME +5.0 V +24.0 V
2 CONNECTOR PIN CON 35V PIN: 11,
13, 15
GND PIN: 12, 14, 16
CON 324V PIN: 3, 5,
7, 9
GND PIN: 4, 6, 8, 10
3 Rated Output +5 V ± 5%
(4.75~5.25 V)
+24 V ± 10%
(21.6~26.4 V)
4 Max. Output Current 3 A 4.4 A
5 Peak Loading Current 3.6 A 5.3 A 1ms
6 RIPPLE NOISE
Voltage
100mVp-p Under 500mVp-p
7 Maximum Output 15 W 105.6 W
8 Peak Output 18 W 127.2 W 1ms
9 Protection for
Loading Shortage
and Overflowing
Current
Shut down or Fuse
Protection
Shut down or Output
Voltage Drop

Xerox Phaser 3250 Specifications

General

Color	No
Print technology	Laser
Maximum resolution	600 x 600 DPI
Warm-up time (from sleep mode)	15 s
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	28 ppm
Internal memory	32 MB
Maximum internal memory	160 MB
Sound power level (standby)	29 dB
Sound pressure level (printing)	54 dB
Total input capacity	251 sheets
Maximum input capacity	501 sheets
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Functions	Print
I/O ports	USB 2.0
Device manager	Printer Setting Utility for Windows
Package length	561.33 mm
Depth (imperial)	14.5 \
Width (imperial)	14.3 \
Height (imperial)	9.4 \
Weight (imperial)	26.19 lbs
Power requirements	240 V, 50/60 Hz
Storage drive type	N/A
Hardware scan resolution	1200 x 1200 DPI
Storage temperature (T-T)	32 - 104 °F
Power consumption (active)	400 W
Compatible operating systems	Fedora Core 1, Red Hat 9, SUSE 9 Windows 2000/Vista
Non-operating relative humidity (non-condensing)	20 - 80 %
Country of origin	China
Maximum duty cycle	30000 pages per month
Recommended duty cycle	4000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	70 W
Power consumption (PowerSave)	11 W
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	10 - 80 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 2004/108/EC, 2006/95/EC
Package width	472.43 mm
Package height	342.89 mm
Package weight	11884.3 g

Weight and Dimensions

Depth	369 mm
Width	364 mm
Height	239.2 mm
Dimensions (WxDxH)	364 x 369 x 239.2 mm
