Xerox Phaser 3330

Troubleshooting
Xerox Internal Use Only Phaser 3330 and WorkCentre 3335/3345
Service Manual
2-63
Replace Toner Cartridge or SMart Kit Drum Cartridge
The Toner Cartridge is near the end of life. The error is displayed when the machine encounters the
Toner Cartridge life based on a set number of pages.
Applicable Errors
• 09-200: Toner Cartridge Empty
• 09-400: Replace SMart Kit Drum Cartridge
Initial Actions
• Turn the printer off and then on again.
• If the problem persists continue troubleshooting.
Troubleshooting Reference Table
Troubleshooting Procedure Table
Applicable Parts Wiring and Plug/Jack Map Reference
• Toner Cartridge or Drum Cartridge. See
Xerox Supplies and Accessories
• Phaser 3330 Main PWB Connector Designators
• Phaser 3330 Control Panel PWB
• Wiring Diagrams for P3330/WC3335/WC3345
• WorkCentre 3335/3345 Main PWB Connector Designators
•DADF PWB
•SMPS PWB
Step Actions and Questions Yes No
1. Replace the Toner Cartridge or Drum
Cartridge. Xerox Supplies and Accessories.
Go to Step 2. Complete.
2. If the problem persists, check the wiring to
the CRUM connection CN4 on the Main
PWB.
Complete. -
