Xerox Phaser 4620 - Page 227

5/2011
4-105
Phaser 4600/4620 Printer Service Manual
REP 10.14
Repairs
Revision - Xerox Internal Use Only
Figure 9 Release the thermostat holder
13. Remove the Fuser Gear from the Heat Roller.
Figure 10 Remove the Fuser Gear
