Xerox Phaser 4620 User Manual

5/2011
6-31
Phaser 4600/4620 Printer Service Manual
dC330
General Procedures/Information
Revision - Xerox Internal Use Only
Output Components
When the appropriate code is entered, the component is activated and its status appears on
the Control Panel.
Go to the appropriate table:
• Table 9 Output Codes 04 IOT Motors
• Table 10 Output Codes 06 Laser Unit
• Table 11 Output Codes 08 Feeder motors and clutches
• Table 12 Output Codes 09 Xerographics
• Table 13 Output Codes 10 Fuser drive
• Table 14 Output Codes 12 Finisher/Mailbox drive
08-300 T3 Feed Sensor Tray 3 Take Away Sensor High/Low
08-400 T4 Feed Sensor Tray 4 Take Away Sensor High/Low
08-500 Regi Sensor Registration Sensor High/Low
08-550 T5 Feed Sensor Tray 5 Take Away Sensor High/Low
08-600 Fuser Exit Sensor Fuser Exit Sensor High/Low
08-650 T6 Feed Sensor Tray 6 Take Away Sensor High/Low
08-700 Duplex Jam1 Duplex Jam Sensor High/Low
08-720 Out-bin Full Sensor Stack Full Sensor High/Low
Table 6 Input Codes 09
Code Display Name Description General
09-110 MHV Bias Read Detects the MHV value on the
MHV roller. Use in conjunction
with 09-100.
Displays MHV value =
XXX
09-310 THV Bias Read Detects the THV value. Use in
conjunction with 09-300 and
09-400.
Displays THV value =
XXX
09--700 Toner Sensor TC sensor in developer Displays value =
X.XX volts
Table 7 Input Codes 10
Code Display Name Description General
10-200 Fuser Temperature A Reports Fuser temperature as
measured at thermistor A.
Displays temperature in
degrees C = XXX
10-210 Fuser Temperature B Reports Fuser temperature as
measured at thermistor B.
Displays temperature in
degrees C = XXX
10-420 Fuser Motor Forward
Ready
Test Fuser motor operation. High = normal speed
Low = abnormal speed
10-910 Fuser Home Sensor Detect home position High/Low
Table 8 Input Codes 12
Code Display Name Description General
12-800 Entrance Sensor Finisher Entrance Sensor High/Low
12-805 Exit Sensor Finisher Exit Sensor High/Low
12-815 Front Jog Home Sensor Right Tamper Home Position High/Low
12-820 Rear Jog Home Sensor Left Tamper Home Position High/Low
12-825 Support Finger Home
Sensor
Support Finger Home Position High/Low
12-840 Stacker Top Sensor Stacker Top Sensor High/Low
12-845 Stacker Bottom Switch Stacker Full Sensor High/Low
12-850 Staple Home Sensor Staple Home Position High/Low
12-855 Staple Ready Sensor Self Priming Sensor High/Low
Table 5 Input Codes 08
Code Display Name Description General
12-860 Low Staple Sensor Low Staple Sensor High/Low
12-870 Staple Door Switch Staple Door Interlock High/Low
12-890 Diverter Home Sensor Exit Gate Sensor High/Low
12-895 Jam Cover Sensor Rear Door Sensor High/Low
12-900 Diverter Home Sensor Exit Gate Sensor High/Low
12-905 Mailbox Entrance Sensor Mailbox Entrance Sensor High/Low
12-910 Mailbox Bin1 Full Mailbox Tray 1 Stack Full High/Low
12-911 Mailbox Bin1 Empty Mailbox Tray 1 No Paper High/Low
12-915 Mailbox Rear Door Mailbox Rear Door Interlock High/Low
12-920 Mailbox Bin2 Full Mailbox Tray 2 Stack Full High/Low
12-921 Mailbox Bin2 Empty Mailbox Tray 2 No Paper High/Low
12-925 Upper Diverter Home Upper Diverter Home Position High/Low
12-930 Mailbox Bin3 Full Mailbox Tray 3 Stack Full High/Low
12-931 Mailbox Bin3 Empty Mailbox Tray 3 No Paper High/Low
12-940 Mailbox Bin4 Full Mailbox Tray 4 Stack Full High/Low
12-941 Mailbox Bin4 Empty Mailbox Tray 4 No Paper High/Low
12-945 Lower Diverter Home Lower Diverter Home Position High/Low
Table 9 Output Codes 04
Code Display Name Description General
04-100 Main BLDC Motor Run the Main Drive motor On/Off
04-120 Main Fan Run the SMPS Fan On/Off
04-181 K Dev motor Run the developer motor On/Off
04-191 K Dev motor ready Run the developer motor High/Low
04-200 Exit Motor Forward Fast Run the Exit Drive Assembly On/Off
04-220 Exit Motor Reverse Reverse the Exit Drive On/Off
04-230 Duplex Motor Forward Run the Duplex Drive On/Off
04-580 Feed BLDC Motor Run the Feed Drive Assembly On/Off
04-590 Feed BLDC Motor Ready Feed Drive Assembly On/Off
Table 8 Input Codes 12
Code Display Name Description General

Xerox Phaser 4620 Specifications

General

Operating temperature (T-T)	50 - 90 °F
Operating relative humidity (H-H)	20 - 80 %
Color	No
I/O ports	10/100/1000 BaseT Ethernet, USB 2.0
Depth (min)	541 mm
Height (min)	420 mm
Minimum width	476 mm
Minimum weight	34.6 kg
Package length	698.49 mm
Print technology	Laser printing
Mac compatibility	Yes
Security features	Audit log, HTTPS, Image overwrite security, IP filtering, IPSec, Network authentication, SNMPv3, 802.1x
Storage drive type	Optional
Print memory (standard)	256 MB
Power consumption (active)	900 W
Minimum storage drive space	160 GB
Power consumption (standby)	93 W
Power consumption (PowerSave)	10 W
Storage media	HDD
Maximum internal memory	768 MB
Sound power level (standby)	39 dB
PCL fonts	93
Certification	Class 1 Laser Product, CE Marked, EMC Directive 89/336/EEC, EN 55022 Class B, EN 55024, FCC Part 15, Class B, Low Voltage Directive 73/23/EEC, RoHS Directive 2002/95/EC
Country of origin	China
Maximum duty cycle	275000 pages per month
Number of PostScript fonts	136
Number of print cartridges	1
Total input capacity	550 sheets
Total output capacity	500 sheets
Maximum input capacity	2000 sheets
Multi-Purpose tray input capacity	100 sheets
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	7.8 s
Print speed (black, normal quality, A4/US Letter)	65 ppm
Display	LCD
Package weight	40200 g
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Card stock, Labels, Pre-Printed, Recycled paper, Transparencies
ISO A-series sizes (A0...A9)	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Export Control Classification Number (ECCN)	EAR99

Weight and Dimensions

Width	627.37 mm
Height	685.79 mm
Dimensions (WxDxH)	476 x 420 x 541 mm
