Xerox Phaser 4620 User Manual

5/2011
6-32
Phaser 4600/4620 Printer Service Manual
dC330
Revision - Xerox Internal Use Only
General Procedures/Information
Table 10 Output Codes 06
Code Display Name Description General
06-100 LSU Motor Run Laser Unit scan motor On/Off
06-200 LSU LD power Laser diode half power On/Off
06-300 LSU Fan Run Right Chassis Fan On/Off
Table 11 Output Codes 08
Code Display Name Description General
08-810 T1 Pick-up Clutch Tray 1 Feed Clutch On/Off
08-820 T2 Pick-up Clutch Tray 2 Feed Clutch On/Off
08-830 T3 Pick-up Clutch Tray 3 Feed Clutch On/Off
08-840 T4 Pick-up Clutch Tray 4 Feed Clutch On/Off
08-850 Registration Clutch Registration Clutch On/Off
08-855 T5 Pick-up Clutch Tray 5 Feed Clutch On/Off
08-856 T6 Pick-up Clutch Tray 6 Feed Clutch On/Off
08-920 T2 Feed Motor Run Tray 2 Feed Drive Motor On/Off
08-930 T3 Feed Motor Run Tray 3 Feed Drive Motor On/Off
08-940 T4 Feed Motor Run Tray 4 Feed Drive Motor On/Off
08-950 T5 Feed Motor Run Tray 5 Feed Drive Motor On/Off
08-960 T6 Feed Motor Run Tray 6 Feed Drive Motor On/Off
Table 12 Output Codes 09
Code Display Name Description General
09-100 MHV Bias MHV bias voltage on at nor-
mal drive level.
On/Off
09-200 Dev Bias Developer bias voltage on at
normal drive level.
On/Off
09-300 THV Bias THV plus bias voltage on at
normal drive level.
On/Off
09-400 THV Bias THV negative bias voltage on
at normal drive level.
On/Off
09-500 SMPS Fan Run Run SMPS Fan On/Off
09-600 Toner dispense motor Run the toner dispense motor
in the Main Drive Assembly
On/Off
09-950 Erase lamp Toggle the Erase lamp On/Off
Table 13 Output Codes 10
Code Display Name Description General
10-100 Fuser Power On Main Raises Fuser temperature to
180 degree setpoint.
On/Off
10-110 Fuser Power On Side Raises Fuser temperature to
180 degree setpoint.
On/Off
10-400 Fuser Motor Forward Run Fuser Drive Assembly. On/Off
10-500 Rear Fan Run Run Rear Door Fan. On/Off
10-600 Fuser Bias Fuser bias voltage on at nor-
mal drive level.
On/Off
10-900 Fuser Gap Motor Run the Fuser Release Drive
Assembly
On/Off
Table 14 Output Codes 12
Code Display Name Description General
12-100 Entrance Motor Run Finisher entrance motor
for about 5 sec.
On/Off
12-110 Exit Motor Run Finisher Transport Motor
for about 5 sec.
On/Off
12-120 Feed Motor Run Mailbox Transport Motor
for about 5 sec.
On/Off
12-300 Front Jog Home Move right tamper to home
position
On
12-310 Front Jog Stand Move right tamper to stand
position
On
12-320 Rear Jog Home Move left tamper to home
position
On
12-330 Rear Jog Stand Move left tamper to stand
position
On
12-400 Support Finger Home Move supporter to home posi-
tion
On
12-410 Support Finger Stand Move supporter to stand posi-
tion
On
12-600 Stacker Down Lower Stacker Tray On
12-610 Stacker Up Raise Stacker Tray On
12-700 Stapler Staple when no cartridge On
12-885 Diverter Motor Run entrance motor to actu-
ate exit gate
On/Off
12-935 Upper Diverter Motor Cycle upper diverter between
three positions
On/Off
12-955 Lower Diverter Motor Cycle lower diverter between
three positions
On/Off
Table 13 Output Codes 10
Code Display Name Description General

Xerox Phaser 4620 Specifications

General

Operating temperature (T-T)	50 - 90 °F
Operating relative humidity (H-H)	20 - 80 %
Color	No
I/O ports	10/100/1000 BaseT Ethernet, USB 2.0
Depth (min)	541 mm
Height (min)	420 mm
Minimum width	476 mm
Minimum weight	34.6 kg
Package length	698.49 mm
Print technology	Laser printing
Mac compatibility	Yes
Security features	Audit log, HTTPS, Image overwrite security, IP filtering, IPSec, Network authentication, SNMPv3, 802.1x
Storage drive type	Optional
Print memory (standard)	256 MB
Power consumption (active)	900 W
Minimum storage drive space	160 GB
Power consumption (standby)	93 W
Power consumption (PowerSave)	10 W
Storage media	HDD
Maximum internal memory	768 MB
Sound power level (standby)	39 dB
PCL fonts	93
Certification	Class 1 Laser Product, CE Marked, EMC Directive 89/336/EEC, EN 55022 Class B, EN 55024, FCC Part 15, Class B, Low Voltage Directive 73/23/EEC, RoHS Directive 2002/95/EC
Country of origin	China
Maximum duty cycle	275000 pages per month
Number of PostScript fonts	136
Number of print cartridges	1
Total input capacity	550 sheets
Total output capacity	500 sheets
Maximum input capacity	2000 sheets
Multi-Purpose tray input capacity	100 sheets
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	7.8 s
Print speed (black, normal quality, A4/US Letter)	65 ppm
Display	LCD
Package weight	40200 g
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Card stock, Labels, Pre-Printed, Recycled paper, Transparencies
ISO A-series sizes (A0...A9)	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Export Control Classification Number (ECCN)	EAR99

Weight and Dimensions

Width	627.37 mm
Height	685.79 mm
Dimensions (WxDxH)	476 x 420 x 541 mm
