Xerox Phaser 4620 User Manual

5/2011
2-55
Phaser 4600/4620 Printer Service Manual
09-900-00, 09-910-00, 09-920-00
Status Indicator RAPS
Revision - Xerox Internal Use Only
09-900-00, 09-910-00 Invalid Drum Cartridge RAP
09-900-00 Non-Xerox Drum Cartridge detected.
09-910-00 Non-Xerox Drum Cartridge detected.
BSD-Reference: WD 6
Initial Actions
• Install a genuine Xerox Drum Cartridge.
• Cycle system power.
Procedure
WARNING
Switch off the electricity to the machine. Disconnect the power cord from the customer
supply while performing tasks that do not need electricity. Electricity can cause death or
injury. Moving parts can cause injury.
Replace the Drum Cartridge with a genuine Xerox cartridge with the proper SKU. The error
message is displayed.
YN
Perform SCP 6 Final Actions.
Check the Drum Cartridge CRUM connector. The connector is clean and undamaged.
YN
Clean or repair the CRUM connector.
Remove the Right Cover (REP 28.2) and reseat CN16 on the MCU Board. The error mes-
sage is displayed.
YN
Reassemble and perform SCP 6 Final Actions.
Replace these components in order until the error is corrected.
1. Drum Cartridge
2. MCU Board, PL 3.10 Item 3
09-920-00 Transfer Unit Error RAP
09-910-00 The Transfer Roller high voltage contact point is not connected or is dirty.
BSD-Reference: WD 11
Initial Actions
• Reseat the Transfer Roller.
• Clean the high voltage contact.
Procedure
WARNING
Switch off the electricity to the machine. Disconnect the power cord from the customer
supply while performing tasks that do not need electricity. Electricity can cause death or
injury. Moving parts can cause injury.
Remove the Transfer Roller and inspect the high voltage contact point. The contact is clean
and undamaged.
YN
Replace the Transfer Roller.
Select dC330 codes 09-300 and 09-310 to check Transfer Roller bias voltage. The reading is
within the operating range.
YN
Remove the Left Cover (REP 28.3) and check the high voltage connection to the HVPS.
The harness is clean, connected and undamaged.
YN
Repair or connect the harness.
Replace the HVPS, REP 1.4.
Replace these components in order until the error is corrected.
1. Transfer Roller, PL 9.10 Item 2
2. HVPS, PL 1.10 Item 1

Xerox Phaser 4620 Specifications

General

Operating temperature (T-T)	50 - 90 °F
Operating relative humidity (H-H)	20 - 80 %
Color	No
I/O ports	10/100/1000 BaseT Ethernet, USB 2.0
Depth (min)	541 mm
Height (min)	420 mm
Minimum width	476 mm
Minimum weight	34.6 kg
Package length	698.49 mm
Print technology	Laser printing
Mac compatibility	Yes
Security features	Audit log, HTTPS, Image overwrite security, IP filtering, IPSec, Network authentication, SNMPv3, 802.1x
Storage drive type	Optional
Print memory (standard)	256 MB
Power consumption (active)	900 W
Minimum storage drive space	160 GB
Power consumption (standby)	93 W
Power consumption (PowerSave)	10 W
Storage media	HDD
Maximum internal memory	768 MB
Sound power level (standby)	39 dB
PCL fonts	93
Certification	Class 1 Laser Product, CE Marked, EMC Directive 89/336/EEC, EN 55022 Class B, EN 55024, FCC Part 15, Class B, Low Voltage Directive 73/23/EEC, RoHS Directive 2002/95/EC
Country of origin	China
Maximum duty cycle	275000 pages per month
Number of PostScript fonts	136
Number of print cartridges	1
Total input capacity	550 sheets
Total output capacity	500 sheets
Maximum input capacity	2000 sheets
Multi-Purpose tray input capacity	100 sheets
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	7.8 s
Print speed (black, normal quality, A4/US Letter)	65 ppm
Display	LCD
Package weight	40200 g
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Card stock, Labels, Pre-Printed, Recycled paper, Transparencies
ISO A-series sizes (A0...A9)	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Export Control Classification Number (ECCN)	EAR99

Weight and Dimensions

Width	627.37 mm
Height	685.79 mm
Dimensions (WxDxH)	476 x 420 x 541 mm
