FRONT BRAKE
4-40
Disassembling the front brake master cylinder
Order Job/Parts to remove Q’ty Remarks
1 Brake master cylinder push rod 1
2 Dust boot 1
3 Circlip 1
4 Brake master cylinder kit 1
5 Brake master cylinder body 1
For assembly, reverse the disassembly pro-
cedure.
