ABS (ANTI-LOCK BRAKE SYSTEM)
4-65
Removing the metering valve, proportioning valve, and brake pipes
Order Job/Parts to remove Q’ty Remarks
Right side cover
Refer to “GENERAL CHASSIS” on page
4-1.
Brake fluid
Drain.
Refer to “BLEEDING THE HYDRAULIC
BRAKE SYSTEM (ABS)” on page 3-14.
1 Brake pipe union bolt/Gasket 2/4
2
Brake pipe (metering valve to right front brake
caliper)
1 Disconnect.
3 Brake pipe (hydraulic unit to metering valve) 1
4 Metering valve 1
5 Brake hose holder 1
6
Brake pipe (proportioning valve to rear brake
hose)
1
7
Brake pipe (hydraulic unit to proportioning
valve)
1
8 Proportioning valve 1
9 Brake pipe union bolt/Gasket 2/4
10 Brake hose union bolt/Gasket 1/2
11
Brake pipe (brake pipe/upper joint assembly to
front brake calipers)
1 Disconnect.
9
9
11
15
16
14
17
9
9
10
13
1
1
1
1
3
2
5
8
6
7
4
12
T
R
.
.
7 Nm (0.7 m
•
kg, 5.1 ft
•
Ib)
T
R
.
.
7 Nm (0.7 m
•
kg, 5.1 ft
•
Ib)
T
R
.
.
7 Nm (0.7 m
•
kg, 5.1 ft
•
Ib)
T
R
.
.
30 Nm (3.0 m
•
kg, 22 ft
•
Ib)
T
R
.
.
16 Nm (1.6 m
•
kg, 11 ft
•
Ib)
T
R
.
.
16 Nm (1.6 m
•
kg, 11 ft
•
Ib)
T
R
.
.
7 Nm (0.7 m
•
kg, 5.1 ft
•
Ib)
T
R
.
.
16 Nm (1.6 m
•
kg, 11 ft
•
Ib)
T
R
.
.
7 Nm (0.7 m
•
kg, 5.1 ft
•
Ib)
T
R
.
.
30 Nm (3.0 m
•
kg, 22 ft
•
Ib)
T
R
.
T
R
.
.
16 Nm (1.6 m
•
kg, 11 ft
•
Ib)
T
R
.
.
7 Nm (0.7 m
•
kg, 5.1 ft
•
Ib)
30 Nm (3.0 m
•
kg, 22 ft
•
Ib)
New
New
New
New
New
New
New
New
