FRONT FORK
4-86
18 Outer tube bushing 1 1 D = 52 mm (2.05 in), l = 12 mm (0.47 in)
19 Outer tube bushing 2 1 D = 51 mm (2.01 in), l = 15 mm (0.59 in)
20 Inner tube bushing 1
21 Outer tube 1
For assembly, reverse the disassembly pro-
cedure.
Disassembling the right front fork leg
Order Job/Parts to remove Q’ty Remarks
17
20
15
21
16
19
18
13
12
11
10
9
5
4
3
6
2
1
7
8
14
35 Nm (3.5 m
•
kg, 25 ft
•
Ib)
T
.R
.
14 Nm (1.4 m
•
kg, 10 ft
•
Ib)
T
.R.
