Yamaha FJR1300A(D) - Page 380

CRANKCASE
5-79
Removing the oil baffle plate and bearings
Order Job/Parts to remove Q’ty Remarks
Connecting rod
Refer to “CONNECTING RODS AND PIS-
TONS” on page 5-85.
Crankshaft/Crankshaft journal bearings Refer to “CRANKSHAFT” on page 5-93.
Transmission Refer to “TRANSMISSION” on page 5-97.
1 Oil baffle plate 2 1
2 Oil delivery pipe 1 1
3 Upper crankcase plate 1
4 Oil baffle plate 3 1
5 Bearing 1
6 Oil seal 1
7 Bearing 1
8 Upper crankcase 1
9 Bearing 1
10 Oil filter cartridge bolt 1
11 Upper crankcase damper 1
12 Crankcase plug 1
10
LS
LS
2
LTLT
LT
LTLT
LT
LT
LT
4
8
3
LT
5
7
6
12
1
9
13
T
R
.
.
12 Nm (1.2 m
•
kg, 8.7 ft
•
Ib)
T
R
.
.
10 Nm (1.0 m
•
kg, 7.2 ft
•
Ib)
T
R
.
.
10 Nm (1.0 m
•
kg, 7.2 ft
•
Ib)
T
R
.
.
10 Nm (1.0 m
•
kg, 7.2 ft
•
Ib)
T
R
.
.
70 Nm (7.0 m
•
kg, 50 ft
•
lb)
New
New
New
New
LS
LS
New
E
E
T
R
.
.
12 Nm (1.2 m
•
kg, 8.7 ft
•
Ib)
11
E
T
R
.
.
20 Nm (2.0 m
•
kg, 14 ft
•
Ib)
(3)
8 Nm (0.8 m
•
kg, 5.8 ft
•
Ib)
T
.R.
