SIGNALING SYSTEM
8-27
NG →
OK ↓
Replace the wire harness if there is an open or short circuit.
• Between rear wheel sensor coupler and ABS ECU coupler.
(white–white)
(gray–gray)
• Between ABS ECU coupler and ECU coupler.
(blue/yellow–blue/yellow)
(white/yellow–white/yellow)
• Between ECU coupler and meter assembly coupler.
(blue/black–blue/black)
(blue/red–blue/red)
2. Check the entire speed sensor wir-
ing.
Refer to TIP.
Properly connect or replace the wire har-
ness.
Replace the hydraulic unit assembly,
ECU or meter assembly.
To Next Page
