SIGNALING SYSTEM
8-26
NG →
OK ↓
The oil level warning light fails to come on.
NG →
OK ↓
NG →
OK ↓
The fuel meter fails to come on.
NG →
OK ↓
NG →
OK ↓
The speedometer fails to operate.
NG →
OK ↓
3. Check the entire signaling system
wiring.
Refer to “CIRCUIT DIAGRAM” on
page 8-21.
Properly connect or replace the wire har-
ness.
Replace the meter assembly.
1. Check the oil level switch.
Refer to “CHECKING THE OIL
LEVEL SWITCH” on page 8-184.
Replace the oil level switch.
2. Check the entire signaling system
wiring.
Refer to “CIRCUIT DIAGRAM” on
page 8-21.
Properly connect or replace the wire har-
ness.
Replace the meter assembly.
1. Check the fuel sender.
Refer to “CHECKING THE FUEL
SENDER” on page 8-185.
Replace the fuel pump.
2. Check the entire signaling system
wiring.
Refer to “CIRCUIT DIAGRAM” on
page 8-21.
Properly connect or replace the wire har-
ness.
Replace the meter assembly.
1. Check the rear wheel sensor.
Refer to “MAINTENANCE OF THE
REAR WHEEL SENSOR AND
SENSOR ROTOR” on page 4-34.
Replace the rear wheel sensor.
