SIGNALING SYSTEM
8-25
The turn signal light, turn signal indicator light or both fail to blink.
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
The neutral indicator light fails to come on.
NG →
OK ↓
NG →
OK ↓
1. Check the rear turn signal light
bulbs and sockets.
Refer to “CHECKING THE BULBS
AND BULB SOCKETS” on page
8-172.
Replace the rear turn signal light bulb,
socket or both.
2. Check the front turn signal light as-
sembly(-ies).
Refer to “CHECKING THE FRONT
TURN SIGNAL LIGHT ASSEM-
BLIES” on page 8-186.
Replace the front turn signal light assem-
bly(-ies).
3. Check the turn signal switch.
Refer to “CHECKING THE
SWITCHES” on page 8-169.
• The turn signal switch is faulty.
• Replace the left handlebar switch.
4. Check the hazard switch.
Refer to “CHECKING THE
SWITCHES” on page 8-169.
• The hazard switch is faulty.
• Replace the right handlebar switch.
5. Check the entire signaling system
wiring.
Refer to “CIRCUIT DIAGRAM” on
page 8-21.
Properly connect or replace the wire har-
ness.
Replace the meter assembly.
1. Check the gear position switch.
Refer to “CHECKING THE
SWITCHES” on page 8-169.
Replace the gear position switch.
2. Check the relay unit (diode).
Refer to “CHECKING THE RELAY
UNIT (DIODE)” on page 8-180.
Replace the relay unit.
