CRUISE CONTROL SYSTEM
8-99
3 Connection of main switch
coupler.
Check the locking condition
of the coupler.
Disconnect the coupler and
check the pins (bent or bro-
ken terminals and locking
condition of the pins).
Improperly connected →
Connect the coupler secure-
ly or replace the wire har-
ness.
Turn the main switch to “ON”.
Push and “SET–” side of the
cruise control setting switch.
Fault code number is not dis-
played → Service is finished.
Fault code number is dis-
played → Go to item 4.
4 Connection of ECU coupler.
Check the locking condition
of the coupler.
Disconnect the coupler and
check the pins (bent or bro-
ken terminals and locking
condition of the pins).
Improperly connected →
Connect the coupler secure-
ly or replace the wire har-
ness.
Turn the main switch to “ON”.
Push and “SET–” side of the
cruise control setting switch.
Fault code number is not dis-
played → Service is finished.
Fault code number is dis-
played → Go to item 5.
5 Check the fuse. (cruise con-
trol system fuse)
Abnormality → Replace the
fuse. (cruise control system
fuse)
Turn the main switch to “ON”.
Push the “SET–” side of the
cruise control setting switch.
Fault code number is not dis-
played → Service is finished.
Fault code number is dis-
played → Go to item 6.
6 Wire harness continuity. Open or short circuit → Re-
place the wire harness.
Between battery and main
fuse coupler.
red–red
Between main fuse coupler
and main switch coupler.
red–red
Between main switch coupler
and fuse box 1 (ignition
fuse).
brown/blue–brown/blue
Between fuse box 1 (ignition
fuse) and cruise control sys-
tem fuse.
red/white–red/white
Between cruise control sys-
tem fuse and left handlebar
switch coupler.
yellow/black–yellow/black
Between left handlebar
switch coupler and ECU cou-
pler.
green/blue–green/blue
Turn the main switch to “ON”.
Push the “SET–” side of the
cruise control setting switch.
Fault code number is not dis-
played → Service is finished.
Fault code number is dis-
played → Go to item 7.
Fault code No. 91
Item
A
Cruise control setting switch “RES+”: open or short circuit is de-
tected.
B
Cruise control setting switch “SET–”: open or short circuit
is detected.
