SELF-DIAGNOSTIC FUNCTION AND DIAGNOSTIC CODE TABLE
9-7
03 Intake air pressure Displays the intake air
pressure.
Shift the transmission into
gear, extend the side-
stand, and then operate
the throttle while pushing
the “ ” side of the
start/engine stop switch.
(If the display value
changes, the perfor-
mance is OK.)
05 Air temperature Displays the air tempera-
ture.
Compare the actually
measured air temperature
with the meter display val-
ue.
06 Coolant temperature When engine is cold: Dis-
plays temperature closer
to air temperature.
When engine is hot: Dis-
plays current coolant tem-
perature.
Compare the actually
measured coolant temper-
ature with the meter dis-
play value.
07 Rear wheel vehicle speed
pulses
Rear wheel speed pulse
0–999
Check that the number in-
creases when the rear
wheel is rotated. The num-
ber is cumulative and
does not reset each time
the wheel is stopped.
08 Lean angle sensor Lean angle sensor output
voltage
Remove the lean angle
sensor and incline it more
than 65 degrees.
• Upright 0.4–1.4
• Overturned 3.7–4.4
09 Fuel system voltage
(battery voltage)
Approximately 12.0 Set the start/engine stop
switch to “ ”, and then
compare the actually mea-
sured battery voltage with
the meter display value. (If
the actually measured bat-
tery voltage is low, re-
charge the battery.)
13 Throttle position sensor
signal 2
• Fully closed position 9–23 Check with throttle valves
fully closed.
• Fully open position 94–108 Check with throttle valves
fully open.
14 Accelerator position sen-
sor signal 1
• Fully closed position 12–22 Check with throttle grip ful-
ly closed position.
• Fully open position 97–107 Check with throttle grip ful-
ly open position.
Diagnostic
code No.
Item Meter display Procedure
