SELF-DIAGNOSTIC FUNCTION AND DIAGNOSTIC CODE TABLE
9-8
15 Accelerator position sen-
sor signal 2
• Fully closed position 10–24 Check with throttle grip ful-
ly closed position.
• Fully open position 95–109 Check with throttle grip ful-
ly open position.
16 Front wheel vehicle speed
pulses
Front wheel speed pulse
0–999
Check that the number in-
creases when the front
wheel is rotated. The num-
ber is cumulative and
does not reset each time
the wheel is stopped.
20 Sidestand switch Extend and retract the sid-
estand (with the transmis-
sion in gear).
• Stand retracted ON
• Stand extended OFF
21 Gear position switch and
clutch switch
Operate the transmission,
clutch lever, and side-
stand.
• Transmission is in neu-
tral
ON
• Transmission is in gear
or the clutch lever re-
leased
OFF
• Clutch lever is squeezed
with the transmission in
gear and when the side-
stand is retracted
ON
• Clutch lever is squeezed
with the transmission in
gear and when the side-
stand is extended
OFF
Diagnostic
code No.
Item Meter display Procedure
