TIGHTENING TORQUES
2-18
Oil pan bolt M6 20 12 Nm (1.2 m·kg, 8.7 ft·lb)
Oil pump drive chain guide bolt M6 2 12 Nm (1.2 m·kg, 8.7 ft·lb)
Oil pump housing cover bolt M6 3 12 Nm (1.2 m·kg, 8.7 ft·lb)
Oil level switch bolt M6 2 10 Nm (1.0 m·kg, 7.2 ft·lb)
Throttle cable holder bolt M5 2 4 Nm (0.4 m·kg, 2.9 ft·lb)
Throttle body joint clamp screw M5 8 3 Nm (0.3 m·kg, 2.2 ft·lb)
Air filter case joint clamp screw M4 4 4 Nm (0.4 m·kg, 2.9 ft·lb)
Air filter case and rear lower fuel
tank bracket bolt
M6 2 8 Nm (0.8 m·kg, 5.8 ft·lb)
Fuel rail screw M6 2 5 Nm (0.5 m·kg, 3.6 ft·lb)
Intake air pressure sensor screw M5 1 3.5 Nm (0.35 m·kg, 2.5 ft·lb)
Atmospheric pressure sensor
screw
M5 1 3.5 Nm (0.35 m·kg, 2.5 ft·lb)
Exhaust pipe assembly nut M8 8 20 Nm (2.0 m·kg, 14 ft·lb)
Exhaust pipe assembly and muf-
fler bolt
M8 2 20 Nm (2.0 m·kg, 14 ft·lb)
Exhaust pipe assembly bolt M8 2 17 Nm (1.7 m·kg, 12 ft·lb)
Muffler bolt M10 2 25 Nm (2.5 m·kg, 18 ft·lb)
Muffler protector bolt M6 1 10 Nm (1.0 m·kg, 7.2 ft·lb)
Muffler protector clamp screw — 1 5 Nm (0.5 m·kg, 3.6 ft·lb)
Crankcase bolt M9 10 See TIP.
Crankcase bolt (shoulder bolt) M6 2 12 Nm (1.2 m·kg, 8.7 ft·lb)
Crankcase bolt M6 16 10 Nm (1.0 m·kg, 7.2 ft·lb)
Crankcase bolt M6 1 10 Nm (1.0 m·kg, 7.2 ft·lb)
Crankcase bolt M8 2 24 Nm (2.4 m·kg, 17 ft·lb)
Crankcase blind plug M10 1 20 Nm (2.0 m·kg, 14 ft·lb)
Lower crankcase plug bolt M6 1 10 Nm (1.0 m·kg, 7.2 ft·lb)
Generator cover bolt M6 11 12 Nm (1.2 m·kg, 8.7 ft·lb)
Clutch cover bolt M6 10 12 Nm (1.2 m·kg, 8.7 ft·lb)
Middle gear case cover bolt M6 9 See TIP.
Pickup rotor cover bolt M6 8 12 Nm (1.2 m·kg, 8.7 ft·lb)
Rear balancer cover bolt M6 4 12 Nm (1.2 m·kg, 8.7 ft·lb)
Oil baffle plate 1 bolt M6 3 10 Nm (1.0 m·kg, 7.2 ft·lb)
Oil baffle plate 2 bolt M6 3 10 Nm (1.0 m·kg, 7.2 ft·lb)
Oil guide plate bolt M6 2 10 Nm (1.0 m·kg, 7.2 ft·lb)
Damper cover bolt (middle gear
case cover)
M6 4 10 Nm (1.0 m·kg, 7.2 ft·lb)
Oil baffle plate 3 bolt M6 2 10 Nm (1.0 m·kg, 7.2 ft·lb)
Upper crankcase plate bolt M6 1 12 Nm (1.2 m·kg, 8.7 ft·lb)
Item
Thread
size
Q’ty Tightening torque Remarks
LT
LT
E
E
E
LT
E
LT
LT
LT
LT
LT
LT
LT
