Yamaha FJR1300A(D) - Page 90

TIGHTENING TORQUES
2-19
Upper crankcase damper bolt M6 3 12 Nm (1.2 m·kg, 8.7 ft·lb)
Damper cover bolt (clutch cover) M6 5 12 Nm (1.2 m·kg, 8.7 ft·lb)
Stator coil assembly lead holder
bolt
M6 1 10 Nm (1.0 m·kg, 7.2 ft·lb)
Main gallery bolt M20 1 8 Nm (0.8 m·kg, 5.8 ft·lb)
Starter clutch bolt M8 3 32 Nm (3.2 m·kg, 23 ft·lb)
Clutch boss nut M20 1 90 Nm (9.0 m·kg, 65 ft·lb)
Use a
lock
washer.
Clutch spring bolt M6 6 8 Nm (0.8 m·kg, 5.8 ft·lb)
Clutch release cylinder bolt M6 3 10 Nm (1.0 m·kg, 7.2 ft·lb)
Clutch hose union bolt M10 2 30 Nm (3.0 m·kg, 22 ft·lb)
Clutch release cylinder bleed
screw
M8 1 5 Nm (0.5 m·kg, 3.6 ft·lb)
Main axle assembly screw M6 3 12 Nm (1.2 m·kg, 8.7 ft·lb)
Stake.
Middle drive pinion gear nut M22 1 160 Nm (16.0 m·kg, 115 ft·lb)
Use a
lock
washer.
Middle drive shaft bearing hous-
ing bolt
M6 3 12 Nm (1.2 m·kg, 8.7 ft·lb)
Bearing retainer (middle drive
shaft)
M88 1 110 Nm (11.0 m·kg, 80 ft·lb) Stake.
Middle driven pinion gear nut M28 1 180 Nm (18.0 m·kg, 130 ft·lb)
Stake.
Bearing retainer (middle driven
shaft)
M68 1 110 Nm (11.0 m·kg, 80 ft·lb) Stake.
Middle driven shaft bearing hous-
ing bolt
M8 3 25 Nm (2.5 m·kg, 18 ft·lb)
Shift drum retainer bolt M6 2 10 Nm (1.0 m·kg, 7.2 ft·lb)
Shift shaft spring stopper M8 1 22 Nm (2.2 m·kg, 16 ft·lb)
Stator coil assembly bolt M6 3 10 Nm (1.0 m·kg, 7.2 ft·lb)
Gear position switch bolt M5 2 4 Nm (0.4 m·kg, 2.9 ft·lb)
Crankshaft position sensor bolt M5 2 4 Nm (0.4 m·kg, 2.9 ft·lb)
O
2
sensor
M18 1 45 Nm (4.5 m·kg, 32 ft·lb)
Coolant temperature sensor M12 1 22 Nm (2.2 m·kg, 16 ft·lb)
Starter motor bolt M6 2 10 Nm (1.0 m·kg, 7.2 ft·lb)
Throttle position sensor screw M5 2 3.5 Nm (0.35 m·kg, 2.5 ft·lb)
Accelerator position sensor bolt M5 2 3.5 Nm (0.35 m·kg, 2.5 ft·lb)
Radiator bolt M6 3 10 Nm (1.0 m·kg, 7.2 ft·lb)
Item
Thread
size
Q’ty Tightening torque Remarks
LT
LT
LT
LT
LT
E
LT
LT
LT
LT
LT
LT
LT
