4-37
CLUTCH
ENG
Order Job name/Part name Q’ty Remarks
13
14
15
16
17
Lock washer
Claw washer
Drive gear (oil pump)
Primary drive gear
Straight key
1
1
1
1
1
For installation, reverse the removal
procedure.
70 Nm (7.0 m  kg)
70 Nm (7.0 m  kg)
8 Nm (0.8 m  kg)
8 Nm (0.8 m  kg)
