6-22
Remove the parts in the order below.
Stand the motorcycle on a level
surface.
Order Job name/Part name Q’ty Remarks
1
2
3
Rear wheel removal
Final gear oil
Bolts
Rear axle nut/washer
Rear wheel assembly
4
1/1
1
Securely support the motorcycle so
there is no danger of it falling over.
Drain
Refer to “FINAL GEAR OIL
REPLACEMENT” in CHAPTER 3.
Refer to “REAR WHEEL REMOVAL/
INSTALLATION”.
For installation, reverse the removal
procedure.
70 Nm (7.0 m kg)
92 Nm (9.2 m kg)
REAR WHEEL AND REAR BRAKE
CHAS
REAR WHEEL
To Next Page
