Yamaha XVS6501997 - Middle Gear; Middle Driven Pinion Gear

4-69
Order Job name/Part name Q’ty Remarks
1
2
3
4
5
6
7
8
9
10
11
12
13
Middle driven pinion gear removal
Engine assembly
Bolts
Shim
Circlips
Bearings
Yoke
Nut
Yoke
Collar
Bearing housing/O-ring
Spring retainers
Spring seat
Damper spring
Damper cam
4
1
4
4
1
1
1
1
1/1
2
1
1
1
Remove the parts in the order below.
Refer to “ENGINE REMOVAL”.
Refer to “MIDDLE DRIVEN PINION
GEAR REMOVAL/INSTALLATION”.
25 Nm (2.5 m  kg)
90 Nm (9.0 m  kg)
MIDDLE GEAR
ENG
MIDDLE GEAR
MIDDLE DRIVEN PINION GEAR
