Yamaha XVS6501997 - Breather Hose Inspection; Exhaust System Inspection

3-21
BREATHER HOSE INSPECTION/
EXHAUST SYSTEM INSPECTION
INSP
ADJ
CAUTION:
20 Nm (2.0 mkg)
25 Nm (2.5 mkg)
20 Nm (2.0 mkg)
25 Nm (2.5 mkg)
20 Nm (2.0 mkg)
BREATHER HOSE INSPECTION
1. Remove:
 Cylinder head cover (rear cylinder)
Refer to “ENGINE REMOVAL” in CHAP-
TER 4.
2. Inspection:
 Breather hose
1
Cracks/damage  Replace.
Loose connection  Connect properly.
Make sure that the crankcase breather hose
is routed correctly.
EB303160
EXHAUST SYSTEM INSPECTION
1. Inspect:
 Exhaust pipe (front)
1
 Exhaust pipe joint (rear)
2
 Muffler assembly (lower)
3
 Muffler assembly (upper)
4
Cracks/damage  Replace.
 Gaskets
5
Exhaust gas leaks  Replace.
2. Check:
 Nut
6
 Nut
7
 Bolt
8
 Bolts
9
 Screws
10
