Yamaha XVS6501997 - Clutch Assembly

4-36
Order Job name/Part name Q’ty Remarks
1
2
3
4
5
6
7
8
9
10
11
12
Clutch assembly removal
Oil pump driven gear
Clutch springs
Pressure plate
Push plate/push rod #1
Ball
Friction plates
Clutch plates
Nut/locknut
Clutch boss
Thrust washer
Nut (primary drive gear)
Clutch housing
Push rod #2
5
1
1/1
1
6
5
1/1
1
1
1
1
1
Remove the parts in the order below.
Refer to “OIL PUMP”.
Refer to “CLUTCH INSTALLATION”.
Refer to “CLUTCH REMOVAL/INSTAL-
LATION”.
Refer to “PRIMARY DRIVE GEAR
REMOVAL/INSTALLATION”.
Refer to “INSTALLATION”.
70 Nm (7.0 m  kg)
70 Nm (7.0 m  kg)
8 Nm (0.8 m  kg)
8 Nm (0.8 m  kg)
CLUTCH
ENG
CLUTCH ASSEMBLY
