Yamaha XVS6501997 - Cable Routing

2-26
CABLE ROUTING
SPEC
10 Horn
11 Headlight lead
12 Right handlebar switch lead
13 Spark plug lead
14 Fuel hose
15 Main switch lead
16 Fuel pump lead
17 Main switch
18 Fuel pump
1 Clutch cable
2 Left handlebar switch lead
3 Fuel tank breather hose
4 Speedometer cable
5 Speedometer
6 Speedometer light leads
7 Rectifier/regulator
8 Rear brake switch lead
9 Sidestand switch lead
EB206000
CABLE ROUTING
