4-53
Order Job name/Part name Q’ty Remarks
1
2
3
4
5
Crankcase separation
Engine assembly
Cylinder head
Cylinder and piston
Clutch assembly
Shift shaft
Oil pump assembly
AC magneto and starter clutch
Middle drive pinion gear
Timing chain guide (rear-intake)
Timing chain guide (front-exhaust)
Timing chains
Oil strainer cover
Oil seal
1
1
2
1
1
Remove the parts in the order below.
Refer to “ENGINE REMOVAL”.
Refer to “CYLINDER HEADS”.
Refer to “CYLINDERS AND PISTONS”.
Refer to “CLUTCH”.
Refer to “SHIFT SHAFT”.
Refer to “OIL PUMP”.
Refer to “AC MAGNETO AND
STARTER CLUTCH”.
Refer to “MIDDLE GEAR”.
10 Nm (1.0 m kg)
24 Nm (2.4 m kg)
24 Nm (2.4 m kg)
10 Nm (1.0 m kg)
10 Nm (1.0 m kg)
24 Nm (2.4 m kg)
10 Nm (1.0 m kg)
CRANKSHAFT AND CONNECTING RODS
ENG
CRANKSHAFT AND CONNECTING RODS
CRANKCASE
To Next Page
